Specifications:

• Accuracy: ≤±1.0%FS
• Brand Name: YD WZYDDZ
• Certification: CE
• Electrical connection: Direct cable
• Electromagnetism Compatibility: EN50051-1
• Explosion-proof class: Exia2CT6
• Hign-concerned Chemical: None
• Housing material: 304 Stainless Steel
• Max Measuring Range: 100 - 199 Bar
• Measuring range: 0-60Mpa gauge pressure
• Model Number: YD4080
• Operating temperature: -40-105℃
• Origin: Mainland China
• Output signal: 0.5-4.5V or 0-5V or 1-5V or 0.4-2.4V(Low power consumption)
• Pressure connection: G1/4 or other
• Protection class: IP65
• Sensor core: ceramic sensor
• Supply voltage: 5VDC
