Specifications:

• Accuracy: 12 Bits
• Analog Bandwidth: 0-200KHz
• Band Width: 0-200KHz
• Origin: CN(Origin)
• IS Battery Demountable: No
• Certification: CE
• Coupling Modes: DC / AC / GND
• Current Consumption: ~120mA @ 9V
• Input Impedance: 1M ohms/20pF
• Maximum Input Voltage: 50Vpk (1X probe)
• Real Time Sampling Rate: 1MSa/s
• Record Length: 1024 points
• Sensitivity Range: 5mV/div-20mV/idv
• Supply Voltage: DC 9V(8-10V)
• Time Base Range: 500s/Div - 10us / Div
• Trigger Modes: Auto, Normal, and Single
• Trigger Position: Center of Buffer
• Model Number: DSO150
• Display Size: 2.9 Inches & Under
• Digital Channels: 1
• Brand Name: FNIRSI
• DIY Supplies: ELECTRICAL
